Switching

In point level detection, a point level switch detects when a certain predefined level is reached.

Such a device is employed when it is not necessary to measure every possible intermediate level, as is the case with continuous level measurement.

A switching command starts or stops filling equipment such as conveyors or pumps.

Point level switches outputting a binary signal can be integrated into a process control system.

Point level detection systems can be used in liquids, pastes, powders or coarse bulk solids.

Typical applications for level switches are:

  • minimum or maximum detection
  • leak detection
  • overfill protection
  • in process tanks, storage tanks, silos and pipelines.

VEGASWING 61 – Vibrating Level Switch for Liquids

Videos

Description & Features

Application area:
Liquids [density: > 0.5 … 2.5 g/cm³ (0.018 … 0.09 lbs/in³)]

The VEGASWING 61 is a universal level switch for use in all liquids. Independent of the mounting position, it detects reliably with millimeter accuracy the limit level. The instrument can be used as an empty or full detector, as approved overfill protection, dry run protection or pump protection in vessels and pipelines. The VEGASWING 61 offers maximum reliability in a wide application range.

VEGASWING 61 – Vega Official Website

Resources


Do you require a different solution? Please visit the manufacturer's website for more products!
VEGA Official Website

VEGASWING 63 – Vibrating Level Switch with Tube Extension for Liquids

Videos

Description & Features

VEGA

Application area:
Liquids [density: > 0.5 … 2.5 g/cm³ (0.018 … 0.09 lbs/in³)]

VEGASWING 63 is used as a universal level switch in all liquids. Independent of the mounting position it detects reliably with millimetre accuracy the level. The instrument can be used in vessels as an empty or full detector, as approved overfill protection, dry run protection or pump protection. The position of the switching point is determined through the tube extension. The VEGASWING 63 offers high reliability and security in a wide application range.

VEGASWING 63 – Vega Official Website

Resources


Do you require a different solution? Please visit the manufacturer's website for more products!
VEGA Official Website

VEGA POINTRAC 31 Radiation-based sensor for level detection

Videos

Description & Features

Application area
Level detection of liquids and bulk solids

The POINTRAC 31 is a radiation-based sensor for universal level detection of liquids and bulk solids. Independent of the mounting location, it monitors reliably the limit level in vessels. The sensor can be used for applications in all industries. Due to the high sensitivity POINTRAC 31 is an economical solution with minimum radiation activity.

POINTRAC 31 – VEGA Official Website


Do you require a different solution? Please visit the manufacturer's website for more products!
VEGA Official Website
